Sleeve Plug Valve

Fangwen Sleeved plug valves are non-lubricated quarter-turn valves that achieve sealing through the use of a compressible sleeve as a sealing member. In many applications they operate virtually maintenance free for decades. Fangwen offers a wide range of plug valves to meet your needs. Sizes range from 1/2" to 24" and end connections include screwed, weld, flanged. Bi-directional flow, simple actuation, lightweight, compact design, and multiport configurations all facilitate improved system design.

Sleeved Plug Valves from Fangwen are designed and manufactured strictly to International Standards API 599, ASME B16.34 or DIN3202, Featured with compact structure & Low emission service.

» Design & Manufactured to API 599, ASME B16.34 or DIN3202

» P.T Ratings to ASME B16.34

» Face to Face dimensions to ASME B16.10

» Flanged Ends to ASME B16.5

» Butt-weld Ends to ASME B16.25

» Threaded Ends to ASME B1.20.1

» Socket-weld Ends to ASME B16.11

» Valves Marking to MSS SP-25

» Inspect & Tested to API 598

» Sizes Ranges from 1/2” thru 20”

» Pressure Ratings from Class 150 to Class 300, PN10 to PN50

» Ends Connections in Flanged R.F or RTJ, Threaded NPT, BSPT, Welded S.W, B.W and Grooved

» Body Materials available in Cast or Forged Carbon Steel ASTM A216 WCB, WCC, ASTM A105N, Low Carbon Steel LCB, LCC, LF2, Alloy Steel WC6, WC9, F11, F22, Stainless Steel CF8, CF8M, CF3, CF3M, A182 F304, F304L, F316, F316L, Duplex & Super Duplex Steel A890 GR. 4A, 5A or F51, Special Materials in Monel, Alu. Bronze C95800, 95600 etc.

» Trim Materials available in 13%Cr, F11, F22, SS304, SS304L, SS316, SS316L and other specials

» Actuations can be equipped with Handwheel, Gear Device, Electric / Pneumatic or Hydraulic Actuators

Fangwen offers Sleeve Plug Valves including, but not limited to

▲PTFE Sleeved Plug Valve ▲Teflon Sleeved Plug Valve

PTFE Sleeved Plug Valve

The Fangwen PTFE Sleeved Plug Valves is designed for the most corrosive and difficult chemical services where drop-tight shutoff is an absolute requirement. Fangwen offers the process industries the widest range of non-lubricated plug valve models, materials, and configurations. This provides customers the flexibility to specify Sleeveline valves to meet virtually all of their applications needs. Fangwen has the answer to your corrosion-resistant, quarter-turn valve needs, whether for on-off or modulating control.

The sleeve is securely nestled in the body. High pressure ribs, top and bottom retention, and 360° port lips all assure sleeve containment.

» Design & Manufactured to API 599, ASME B16.34 or DIN3202 ◆ P.T Ratings to ASME B16.34

» Face to Face dimensions to ASME B16.10 ◆ Flanged Ends to ASME B16.5

» Butt-weld Ends to ASME B16.25 ◆ Threaded Ends to ASME B1.20.1

» Socket-weld Ends to ASME B16.11 ◆ Valves Marking to MSS SP-25

» Inspect & Tested to API 598

» Sizes Ranges from 1/2” thru 20”

» Pressure Ratings from Class 150 to Class 300, PN10 to PN50

» Ends Connections in Flanged R.F or RTJ, Threaded NPT, BSPT, Welded S.W, B.W and Grooved

» Body Materials available in Cast or Forged Carbon Steel ASTM A216 WCB, WCC, ASTM A105N, Low Carbon Steel LCB, LCC, LF2, Alloy Steel WC6, WC9, F11, F22, Stainless Steel CF8, CF8M, CF3, CF3M, A182 F304, F304L, F316, F316L, Duplex & Super Duplex Steel A890 GR. 4A, 5A or F51, Special Materials in Monel, Alu. Bronze C95800, 95600 etc.

» Trim Materials available in 13%Cr, F11, F22, SS304, SS304L, SS316, SS316L and other specials

» Actuations can be equipped with Handwheel, Gear Device, Electric / Pneumatic or Hydraulic Actuators
