Marine Globe Valve

Fangwen Marine Globe Valves are made of Cast Steel, Cast iron or Cast Bronze. Standards to JIS, ASME or Equivalents. Sizes from DN15 through DN300. Ratings available in 5K, 10K, 16K, 20K, etc.

Fangwen offers a variety of Marine Globe Valves in Straight Style, Angle Pattern, which is provided in a complete line of materials in Cast Steel, Cast iron or Cast Bronze. Standards to JIS, ASME or Equivalents. Sizes from 15A thru 300A. Ratings available in 5K, 10K, 16K, 20K or ASME CL125 & CL150.

» JIS F7348 Marine Bronze Globe Valve 16K

» JIS F7346 Marine Bronze Globe Valves 5K

» JIS F7301 Marine Bronze Globe Valves 5k

» JIS F7304 Marine Bronze Angle Valves 16K

» JIS F7347 Marine Bronze Angle Valves 5K

» JIS F7302 Marine Bronze Angle Valves 5k

» JIS F7305 Marine Cast Iron Globe Valves 5k

» JIS F7307 Marine Cast Iron Globe Valve 10K

» JIS F7309 Marine Cast Iron Globe Valve 16K

» JIS F7306 Marine Cast Iron Angle Valve 5K

» JIS F7308 Marine Cast Iron Angle Valve 10K

» JIS F7310 Marine Cast Iron Angle Valve 16K

» JIS F7320 Marine Cast Steel Angle Valve 10K

» JIS F7314 Marine Cast Steel Angle Valve 20K

» JIS F7312 Marine Cast Steel Angle Valve 5K

» JIS F7354 Marine Angle Screw-Down Check Valve 5K

» JIS F7376 Marine Angle Screw-Down Check Valve 10K

» JIS F7378 Marine Angle Screw-Down Check Valve 16K

Standards Compliance:

» Inspect & Test: JIS 7400-1996

» Flanged Dimension to JIS B2220 - 5K, 10K or 16K

Marine Bronze Globe Valve

Bronze bolted cover, screw lift, rising stem, metal seated gland packed globe valve. Outside screw and yoke. Suitable for cold and hot water, seawater, saturated steam, oil and other neutral non aggressive liquids. The valve provides a leak tight shut off with the

capability of being used partially open to regulate flow. Independent third party test and inspection by various classification society surveyor’s can be arranged for shipside and primary isolation duties.

Features & Benefits

» Classification society survey can be arranged

» Can be supplied as SDNR, with or without spring (DIN 86261)

» 3.1 certificates available on request

» Flanges can be drilled to various specifications on request

Pressure & Temperature

DN15 to DN100

16 Bar @ 120°C

10 Bar @ 180°C

DN150 to DN200

10 Bar @ 120°C

6 Bar @ 180°C

DN250 to DN300

6 Bar @ 120°C

4 Bar @ 180°C

Size Range

DN15 – DN 100(1/2” – 4”)

Maximum Working Pressure

Class 150/PN 32/5K/10K

Alternative trim available: - Monel, Brass & Stainless Steel

(Wedge/Stem)

Available: - BSP, NPT, Socket Weld Ends
