Y Strainer

Fangwen Y strainers are a cost-effective solution for the mechanical removal of unwanted solids from liquid, gas or steam lines by means of a perforated or wire mesh straining element. They are used in pipelines to protect pumps, meters, control valves, steam traps, regulators and other process equipment.

Y-Strainers are typically used in applications where the amount of solids to be removed is small, and where frequent clean-out is not required. They are most often installed in gaseous services such as steam, air, nitrogen, natural gas, etc. The compact, cylindrical shape of the Y-strainer is very strong and can readily accommodate the high pressures that are common in this type of service. Pressures up to 6000 psi are not unusual. When steam is being handled, high temperature can be an additional complicating factor. A steam pressure of 1500 psi will often be found at temperatures of 1000°F.

Forged Y Strainer

THE Fangwen FORGED Y STAINER DESIGNING FEATURES

» Forged Steel Body and Cover

» Stainless Steel, Gr. 304 or 316 Screen

» Fusion Bonded Epoxy Coating

» Sizes: DN15 through DN50

» Body Styles: Flanged Ends

» Pressure Class: ANSI #125~#2500, PN10~PN400

» Threaded Drain Plug Device

» Optional Basket and T Type Construction

Applicable Standard:

Design Standard: BS5352

Face to face: factory's standard

End Connection: ASME B16.5,ANSI B16.25,ANSI B1.20.1,ANSI B16.11

Inspection and Test: API 598

Products Range

Size: 1/2" ~ 2" (DN15 ~ DN50)

Rating: ANSI 150lb ~ 1500lb

Body Materials: Carbon Steel, Stainless Steel, Alloy Steel, Duplex Steel.

Screen: SS304,SS316.

Forged Y Type strainer have a number of things to prove its potential presence. Forged type of strainer is economical in cost and commonly found in thousands of pipelines. It blends well with the pipelines that are slightly inclined or horizontal. With the main purpose of removing solid particles from fluids flowing through the pipeline, Forged Y type strainer renders an effective service without reducing the pressure of flow of fluids.
