Eccentric Plug Valve

Fangwen Eccentric Plug Valves feature a rectangular port design that provides wide tolerance seating geometry for lasting superior shutoff. The eccentric plug action and resilient plug facings assure lasting dead-tight shutoff. Standard features include corrosion-resistant bearings, welded nickel seat, grit excluders, and adjustable stem seal packing. Port area options include 100% of standard pipe area for applications where highest flow is required (such as pumped systems), and 70/80% area for non-pumped (gravity feed) systems. The straight-through body design maximizes flow capacity and reduces head loss. Flanged or mechanical joint end connections are available. Eccentric Plug Valves are capable of handling clean and dirty liquids and gases, sludge and slurries.

Fangwen Eccentric Plug valves are designed for applications throughout water and wastewater treatment plants.

Eccentric Plug Valve Designing features:

» Cast or Ductile Iron Body, Disc and Gland

» W.T to AWWA C504-00 Table 2

» Flanged Ends to ANSI B16.1 Class 125 or 250

» Grooved Ends to ANSI AWWA C-606 for D.I or Steel pipes

» Mechanical Joints in Accordance with AWWA C111 (ANSI 21.11)

» Plug is round up to 12" and rectangular for size 14" and larger

» All valves are in accordance with MSSR-SR-108

» Optional Direct Mounting Pad to ISO 5208

» Fusion Bonded Epoxy Coating Int & Ext.

» AWWA C504, MSSR-SR-108, ASME B16.34, MSS SP-108

» ASME B16.10, ASME B16.1-125B, ASME B16.5 150B

» AWWA C606 for D.I or Steel Pipe

» AWWA C111 (ANSI 21.11)

» MSS SP-25

» ISO 5208

» Sizes: NPS2" through NPS42"

» Body Styles: End connections Flanged Ends, Grooved or M.J

» Pressure Class: ANSI #125B, 150B, 250B

» Actuation: Handwheel, Wormgear, Electric, Hydraulic or E-Hydraulic.

Fangwen offers Eccentric Plug Valve including, but not limited to

▲ AWWA C517 Eccentric Plug Valve ▲Cast Iron Eccentric Plug Valve

AWWA C517 Eccentric Plug Valve

Fangwen AWWA C517 Eccentric Plug Valves are designed for applications throughout water and wastewater treatment plants and are designed and manufactured strictly to International Standards AWWA C504, AWWA C517, MSSR-SR-108, ASME B16.34 The Fangwen AWWA C517 Eccentric Plug Valves’s materials are in cast iron ASTM A126 Class B or Ductile Iron A536 Gr. B,. Flanged valves are in full compliance with ANSI B16.1 Class 125, Mechanical Joint Ends to AWWA C111/ANSI 21.11. Grooved End valves to AWWA C606.

The purpose of this standard is to provide minimum requirements for water service, including materials, application, inspection, handling, and shipping.

AWWA C517 Eccentric Plug Valves DESIGNING FEATURES

» Cast or Ductile Iron Body, Disc and Gland

» W.T to AWWA C504-00 Table 2

» Flanged Ends to ANSI B16.1 Class 125 or 250

» Grooved Ends to ANSI AWWA C-606 for D.I or Steel pipes

» Machnical Joints in Accordance with AWWA C111 (ANSI 21.11)

» Plug is round up to 12" and rectangular for size 14" and larger

» All valves are in accordance with MSSR-SR-108

» Optional Direct Mounting Pad to ISO 5208

» Fusion Bonded Epoxy Coating Int & Ext.

» AWWA C517, MSSR-SR-108, ASME B16.34, MSS SP-108

» ASME B16.10, ASME B16.1-125B, ASME B16.5 150B

» AWWA C606 for D.I or Steel Pipe

» AWWA C111 (ANSI 21.11)

» MSS SP-25

» ISO 5208

» Sizes: NPS2" through NPS42"

» Body Styles: End connections Flanged Ends, Grooved or M.J

» Pressure Class: ANSI #125B, 150B, 250B

» Actuation: Handwheel, Wormgear, Electric, Hydraulic or E-Hydraulic.
